article number
▲ new (old) ▼ | ▲ article description: ▼ |
|
1 | | 1 Stück
107176
(14903000) | | Roller carrier/ pendulum arm
for GT 1750 |
 ER00216235 | |  | | ▶ details |
|
|
2 | | 10 Stück
107225
(60300170) | | Pipe clamp SP 325 PP-DP-AS | | | | | ▶ details |
|
|
3 | | 4 Stück
107254 | | Hexagon head screw ISO 8676 M24x1.5x80 | | | | | ▶ details |
|
|
4 | | 8 Stück
105410 | | Washer DIN 125 A 24 | | | | | ▶ details |
|
|
5 | | 4 Stück
110779 | | Hexagon nut ISO 10511 – M24 – 8
with clamping piece, zinc-plated | | | | | ▶ details |
|
|
6 | | 1 Stück
109947
(14906011) | | Attachment
without hole for parabolic spring |  23.2 Kg
ER00024030 | | | | ▶ details |
|
|
7 | | 2 Stück
106387 | | Hexagon screw ISO 4017 M16x40 | | | | | ▶ details |
|
|
8 | | 2 Stück
104639 | | Spring washer DIN 127 B 16.2 | | | | | ▶ details |
|
|
9 | | 2 Stück
104805 | | Washer ISO 7093 - 16 | | | | | ▶ details |
|
|
10 | | 2 Stück
103540
(01900750) | | Hexagon nut ISO 10511 - M16 - 8 | | | | | ▶ details |
|
|
11 | | 1 Stück
107218 | | Bracket for rotary encoder Leue, galvanized |
ER00290883 | | | | ▶ details |
|
|
12 | | 2 Stück
104973 | | Hexagon head screw ISO 4017 M8x20 - 8.8, galvanised | | | | | ▶ details |
|
|
13 | | 2 Stück
104634 | | DIN 127 A 8.1 washer | | | | | ▶ details |
|
|
14 | | 2 Stück
105414 | | Washer ISO 7089 - 8 | | | | | ▶ details |
|
|
15 | | 1 Stück
101131
(50100091) | | Magnet for angle sensor ASM
PRMAG20 |
KKE00180330 | | | | ▶ details |
|
|
16 | | 1 Stück
109958
(14903020) | | Articulated roller support
towards the boom |
ER00040155 | | | | ▶ details |
|
|
17 | | 2 Stück
101974
(60251175) | | Dry plain bearing bush, on role
for GT 1750, BK 090-707580 | | | | | ▶ details |
|
article number new
(article number old) |
Husmann Spare parts catalogue
